Alpinion E- Cube 8 Ultrasound

Alpinion E- Cube 8, Diagnostic Ultrasound

E-Cube 8, Diagnostic Ultrasound
Brand: Alpinion

Smartness for your daily practice

The requirements of patients and medical practitioners are becoming more diverse with the quickly evolving medical setting. We need to react to their requirements and adapt rapidly to the modifications in order to satisfy customer requirements.

The E-CUBE 8 will become an excellent partner for your practice, providing both ease of use and a quick and precise diagnostic process. Individual service and care will be given to your clients and healthcare productivity will also be enhanced. E-CUBE 8 is an intelligent, reliable product with excellent image quality and multi-purpose usability that guarantees high efficiency. The E-CUBE 8 is for you the most reasonable option.

Physical specification

• Width: 532 mm
• Depth: 787 mm
• Height: 1430 mm
• Weight: 55 kg (only system)

System design

• 5 “flat panel monitor and articulated arm
• front handle
• 4 active probe connectors
• 1 pencil probe port
• 4 rotating wheels
• Integrated HDD SSD
• ECG (optional)
• Thermal printer storage
• Installed stereo speaker
• Installed cable management
• System boot up: in 60 sec.

Main Monitor

• 5 “high-definition LED-backlit LCD
• Resolution: 1,920 x 1,080 (16:9 wide)
• 2 M color display
• Contrast: 1:1,000
• IPS (In Plane Switching) technology
• Light and contrast adjustment
• Articulated monitor arm-Swivel: /- 135 °-Tilt: 30 ° /-90 °

Control panel

• Backlit alphanumeric keyboard
• Ergonomic key layout
• 8 TGC control levers
• 3 user-customizable keys
• 5 removable sample holders
• Optional integrated gel warmer (3 temperature levels)
• Low: 31°C — Medium: 34°C — High: 37°C

Touch screen

• 4 “high-definition LED-backlit LCD
• resolution: 1.024 X 768
• 2 M color display
• Computer energy adjustable for brightness and contrast (OSD)
• Main CPU: Intel Core i7-4700EQ 3.2 GHz
• Main memory: 4 GB
• HDD[500 GB ] and SSD[128 GB ]

System Architecture

• Digital Beamforming
• High-Density Transducer Connector
• Transducer Power ViewTM (C- Architecture)
• Triple Multi-Beam
• FleXcanTM
• SensitiViewTM
• Crystal SignatureTM
• MicroFitTM
• Optimal Imaging SuiteTM
• Raw Data Processing
• Nadel Enhancement
• Multi-layer transducer
• Windows7 Embedded Transducer ?

Transducer Type

• Convex
• Micro Conven
• Endo Vacity
• Linear
• Phased
• Volume
