DRE 140 X-ray machine 500MA

DRE 140 X-ray machine 500MA

Features:
GeneratorDRE140
Max. Output40kW
mA range10 ~ 500mA
kV range40 ~ 125kV
mAs range0.4 ~ 630mAs
Power supply1Ø 220VAC 50/60Hz
Exposure time0.004 ~ 10sec
No. of APR216
OptionAEC
X-ray tubeDRE140
Focal spot1.0/2.0mm
Anode heat capacity100kJ (140kHU)
Target angle16°
Voltage range40 – 125kV
Weight16kg
Permanent filtration0.9mmAl
Flat panel detectorDRE140
ScintillatorCSI
Pixel pitch143um
Resolution3.7lp/mm
MTF36% (2.0lp/mm, 70kVp, 1×1)
DQE0.7
Active Area43 x 43.9cm
Pixel matrix3,008 x 3,072
AD conversion14 bits
Energy range40 ~ 150kVp
Power supply1Ø 100 ~ 240VAC 50/60Hz
Dimension512 x 495 x 43mm
Weight16kg
Flat panel detectorDRE140
ScintillatorCSI
Pixel pitch143um
Resolution3.7lp/mm
MTF36% (2.0lp/mm, 70kVp, 1×1)
DQE0.7
Active Area43 x 43.9cm
Pixel matrix3,008 x 3,072
AD conversion14 bits
Energy range40 ~ 150kVp
Power supply1Ø 100 ~ 240VAC 50/60Hz
Dimension512 x 495 x 43mm
Weight16kg
CollimatorDRE140
Power supply1Ø 24VAC 50/60Hz
Max. kVp shield35 x 35cm at SID 65cm
Inherent filtration1.2mmAl
Lamp luminosityOver 160Lux
Lamp time30sec
Field size controlManual

Tube Stand:

Vertical travel distance1,400mm
Transverse travel distance260mm
Min. Tube height (from the floor)550mm
Max. Tube height (from the floor)1,950mm
Column rotation±90°
Tube rotation±180°
Longitudinal travel distance2,400 ~ 3,000mm ,(floor-ceiling fixed type), 1,500mm (floor fixed type)
Power supply24VDC, 3A
WeightDRE140/150

Bucky Stand:

Vertical travel distance1,400mm
Min. Tube height (from the floor)400mm
Max. Tube height (from the floor)1,800mm
Power supply1Ø 16 ~ 24VAC 50/60Hz
Weight120kg
ApplicationDRE140/150

Bucky Table:

Tabletop size2,000 x 745mm
Tabletop height670mm
Tabletop materialAcryl
Longitudinal Travel distance±280mm
Transverse travel distance±140mm
Bucky travel distance±230mm
Max. patient weightMax. 150kg
Power supply1Ø 220VAC 50/60Hz
Weight160kg
ApplicationDRE140/150

Configuration of The System:

ComponentsDRE140 with fixed dual FPDDRE140 with portable FPD
40kW Generatorokok ok
50kW Generator
17″ x 17″ Flat panel detectorok
14″ x 17″ Flat panel detectorok
150kV X-ray tube
125kV X-ray tubeokok ok
Basic ConfigurationTube stand, Bucky stand, Bucky table, PC & monitor, Acquisition Software,- upgradable to floor mounted Tube stand,- for international sales
SKU: HA - 1525 Category:
JPI

Description

DRE 140 X-ray machine 500MA

Specification:

Operation Software

By using a quick and easy-to-use interface, ExamVue software provides an extensive collection of X-ray image analysis instruments. The example provides features for high-performance image processing and measuring.

X-ray Generator

High-frequency generator guarantees a minimal dose of the patient, outstanding reproducibility and superior contrast of the picture.

Flat panel detector

For digital radiographic applications, flat panel detector provides high sensitivity, high resolution, low noise, and excellent image quality. There are infinite clinical applications for portable flat panel detector.

Tube stand

Ergonomically designed pipe stand for table and stand examinations offers the operator with quicker and easier motion.

Bucky stand

Wide range of vertical travel (400 ~ 1,800 mm) enables exposures from the cervical spine to the lower limbs.

Bucky table

The robust table design makes it possible to examine obese patients with a table weight of up to 150 kg. The operator can take care of the patient securely without any unexpected tabletop motion due to the footswitch incorporated into a stable foundation.

The scheme can be used as a dual detector scheme 17 “X 17” or as a single detector scheme 14 “X 17.”
